| Displacement |
350 cid (5736 CC) / 5.7L |
| Cylinder Head |
Cast Iron |
| Cylinders |
90 Degree 8-Cylinder |
| Engine Orientation |
Longitudinal |
| Compression Ratio |
9.4:1 |
| Valve Configuration |
Overhead Valves (2 valves per cylinder) |
| Valve Lifters |
Hydraulic Roller |
| Firing Order |
1 – 8 – 4 – 3 – 6 – 5 – 7 – 2 |
| Bore x Stroke |
4.00" x 3.48" (101.60 x 88.39 mm) |
| Ignition |
Not Included |
| Horsepower |
292 hp @ 4800 rpm (Carburetor) |
| Flywheel Diameter |
14" (Ring Gear Towards Engine) |
| Torque |
370 lb-ft @ 3200 rpm |
| Oil Pan Capacity |
5.5 Quarts (with filter) |
| Emission Controls |
Positive Crankcase Ventilation |
| Block |
Cast Iron GM232-M |
| Main Bearing Caps |
Cast iron GM232-M |
| Crankshaft |
Nodular Iron |
| Camshaft |
5150 Steel Billet |
| Connecting Rods |
Forged - SAE 1141 |
| Warranty |
2 Year Limited (Commercial 90 day) |
